Slitting Machine

Slitting Machine is suitable for slitting and rewinding such various roll materials as BOPP, PET, CPP, CPE, PVC, aluminum foil and paper, etc. and can cut edge, separate and cut material according to different requirements during production.

Type	LFQ-700A	LFQ-1100A	LFQ-1300A
Max.Width of Mother Roll	700mm	1100mm	1300mm
MAX.Diameter of Mother Roll	Dia600mm	Dia600mm	Dia600mm
Width of Final Roll	30-600mm	30-600mm	30-600mm
Slitting and Rewinging Speed	5-160m/min	5-160m/min	5-160m/min
Tolerance of EPC	more or less 0.5mm	0.5mm	0.5mm
Total Power	2.7kw	3.5kw	3.5kw
Weight of Machine	1200kg	1500kg	1800kg
Overall Dimension	200011101400mm	240011101400mm	260011101400mm
