Waste Plastics Recycling Machine

Waste Plastics Recycling Machine

Waste Plastics Recycling Machine is used for recycling of the used and waste plastic materials.Itequipped with automatic constant temperature,clectric changing filter nets.It also can pelletize the croushingmaterial after fitting with a loader.The cutting machine adopts speed regulating motor. which can cut thematcrial according to the feeding speed of the extruder. With such features as high output,low noise,stable performance and easy operation.It is a more ideal waste plastic film regenerative pelletizer.


Main Technical Variables
model
KD -C90
KD -C100
KD -C110
KD -C120
Diameter of Screw
85mm
95mm
105mm
110mm
Major Diameter Ratio (L/D)
20:1-22:1
20:1-22:1
20:1-22:1
20:1-22:1
Rationl Speed of Screw
10-110rpm
10-110rpm
10-110rpm
10-110rpm
Main Motor Power
22kw
30kw
30kw
37kw
Output
60kg/h
90kg/h
110kg/h
130kg/h
Weight
2t
2.1t
2.2t
2.5t
Overall Dimensions(m)
5.8*1.25*1.1
5.9*1.3*1.2
6*1.35*1.3
6.2*1.4*1.35
