Two Color Flexographic Printing Machine

Two Color Flexographic Printing Machine

Two Colour Flexo Printing Machine suitable for printing such packing materials as PE film,PP film,non-woven fabric and roll paper, etc. It is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.

Performance and Features
1. Easy operation, flexible starting, accurate color register.
2. The meter counter can set printing quantity according to the requirements. Stop the machine automatically at the quantity or when the material is cut off.
3. Pneumatic printing cylinder lift and lower, it will stir the printing ink automatically after lifting.
4. The printing ink is spread by the anilox cylinder with even ink color.
5. Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.
6.360 degree countinuous and adjustable longitudinal register device.
7. The frequency control of motor speed adapts to different printing speeds.
8. There are Jogging/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.

Main Technical Variables:



Type
YT-2600
YT-2800
YT-21000
YT-21200
Max. Web Width
600mm
800mm
1000mm
1200mm
Max. Effective Printing Width
560mm
760mm
960mm
1160mm
Range of Repeat Printing Length
180-1200mm
180-1200mm
180-1200mm
180-1200mm
Max. Diameter of Roll Material
450mm
450mm
450mm
450mm
Printing Speed
60m/min
60m/min
60m/min
60m/min
Plate Thickness(Both side
 adhesive tape included)
2.38mm
2.38mm
2.38mm
2.38mm
Total Power
8kw
10kw
12kw
14kw
Weight
800kg
2000 kg
2200 kg
2500
Overall Dimension(m)
2.3*1.6*2.2
2.3*1.8*2.2
2.3*2*2.2
2.3*2.2*2.2
