Four Colors Flexo Printing Machine

Four Colors Flexo Printing Machine

four Colour Flexo Printing Machine suitable for printing such packing materials as polyethylene, polypropylene bag, cellophane and roll paper, etc. It is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.

Plastic Shopping Bag



Performance and Features
1. Easy operation, flexible starting, accurate color register.
2. The meter counter can set printing quantity according to the requirements. Stop the machine automatically at the quantity or when the material is cut off.
3. Pneumatic printing cylinder lift and lower, it will stir the printing ink automatically after lifting.
4. The printing ink is spread by the anilox cylinder with even ink color.
5. Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.
6.360 degree countinuous and adjustable longitudinal register device.
7. The frequency control of motor speed adapts to different printing speeds.
8. There are Jogging/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.

Technical Parameter:



Type
YT-4600
YT-4800
YT-41000
Max.Effective Printing Width
560mm
760mm
960mm
Max.Web Width
600mm
800mm
1000mm
Max.Printing Speed
60m/min
60m/min
60m/min
Max.Mechanical Speed
60 m/min
60 m/min
60 m/min
Max.Diameter of Roll Material
450mm
450mm
450mm
Internal Diameter of Roll Core
76mm
76mm
76mm
Rang of Repeat Printing Length
191-914mm
191-914mm
191-914mm
Accuracy of Registration
+/- 0.5mm
+/- 0.5mm
+/- 0.5mm
Plate Thickness
(Bothside adhesive included)
2.38mm
2.38mm
2.38mm
Heating Power
7Kw
10.5Kw
14Kw
Total Power
11.5Kw
15Kw
18.5Kw
Weight of Machine
3000kg
3500kg
4000kg
Overall Dimension
4.8*1.6*2.4m
4.8*1.8*2.4m
4.8*2*2.4m









OPTIONAL EQUIPMENT:

1) Edge position control

2) Ceramic anilox roller

3) Ink pump

4) Magnetic power brake
