Characteristic :
(1) Mechanical structure: The parts are interchangeable, the parts are easy to obtain, and the wear is low.
(2)Drying method: Separate electric heating box, which can be used for safe and temperature control.
(3)Ink knife method: development type scraper, easy to install without tools.
(4)Transmission system: Hardened high-precision geared motor with multiple buttons for easy operation.
(5)Receiving transmission: Miniature geared motor, driving magnetic powder clutch, with PLC control tension stability.
(6)Plate roll specification: repeat length is 5MM
| six colors central drum flexo printing machine |
| four colors central drum flexo printing machine |
| CI Type Flexo Press |
| CI Type Flexo Printing Machine |
| Central Impression Drum Flexo Printing Machine |
| Economic Central Drum CI Flexo Printing Machine |
| CIType Central Drum Plastic Film Flexo Printing Machine |
| CI Type Flexo Printing Machine |
| central drum flexo printing machine |
Main Parameter:
| KDCI-6600 | KDCI-6800 | KDCI-61000 | KDCI-61200 | |
| Max.material width | 600mm | 800mm | 1000mm | 1200mm |
| Max.printing width | 560mm | 760mm | 960mm | 1160mm |
| Printing colors | 6 colors (6+0,5+1,4+2,3+3 ) | |||
| Printing length | 300-1000mm | |||
| Machine speed | 200m/min | |||
| Printing speed | 150-180m/min | |||
| Suitable Material | PAPER∶15-300g/m²、NONWOVEN∶15-120G、PVC∶10-120um、OPP10-100um、BOPP∶10-100um、PE∶15-150μm、NY∶10-120μm、PET∶10-100μm、CPP∶10-100μm | |||
| Material of Plate | Resin | |||
| Constitution of Printing | Ceramic Anilox roller 、chamber doctor blade 、printing Cylinder for printing length 400mm、 Camera & PLC touch screen control | |||
| Printing precision | +/-0.15mm | |||
| Thickness of Plate (including the glue) | 1.7mm (please note us for different thickness) | |||
| Machine Voltage | 380V 50/60HZ 3PH | |||
Components List
| Brand | |
| Human-computer Interface | China |
| PLC programming controller | Taiwan |
| Relay | Schneider. France |
| Contactor 、Button 、Potentiometer | Schneider. France |
| Breaker | France |
| Temperature controller | Schneider. France |
| Inverter | Delta brand Taiwan |
| Auto EPC | China |
| Bearing for anilox roller, printing roller, Central drum | Japan |
