Optional Device:
1)Auto Loader
2)Air Compressor
3)Rotary Die Head
4)Up and Down
5)Embossing Cylinder
6)Air Shaft
7)Masterbatch Dosing device
8)Automatic Winder Changer
9) Corona treatment
| Model | SJ-B50 | SJ-B55 | SJ-B60 | SJ-B65-1 |
| Material | LLDPE raw material | |||
| Usage | Hot shrink film | |||
| Die-head | Special structure for hot shrink film | |||
| Diameter of screw | φ50 | φ55 | φ60 | φ65 |
| Reduced diameter of film | 100-600 mm | 200-800 mm | 300-1000 mm | 400-1200 mm |
| One side film Thickness | 0.015-0.10 mm | |||
| Max.capacity (Kg/h) | 35 | 50 | 60 | 80 |
| Ratio of Screw L/D | 28:1 | 28:1 | 28:1 | 28:1 |
| Screw material | 38CrMoAl | 38CrMoAl | 38CrMoAl | 38CrMoAl |
| Power of main motor | 11kw | 15kw | 18.5kw | 22kw |
| Power of Traction | 1.1 kw | 1.1 kw | 1.5 kw | 1.5 kw |
| Heating Power | 11kw | 13kw | 19kw | 21kw |
| Machine size | 4.8×1.9×3.8m | 5.5×2.1×4.6m | 6.5×2.3×5.2m | 6.5×2.5×5.2m |
| Weight(T) | 1.5T | 2T | 2.3T | 2.6T |
| Winder structure | Double Side Winder(Back to back winder) | |||
| Power Voltage | 220V,380V,440V,480V(Customized based on request,For example: USA 480V 60Hz, Mexico 440V/220V 60Hz, Saudi Arabia 380V 60Hz, Nigeria 415V 50Hz…) | |||
| Delivery time | 30-40days | |||
| Material Core Diameter | 76mm(3 inch) | |||
| Machine Working Time | 24 hours * 7 days | |||
| Warranty | 1 year | |||
| Optional Devices | Auto loader, masterbatch dosing system, rotary die head, bubble controller, corona treater, embossing roller, automatic winder | |||
| Technical Assistance | Engineers available to service machinery overseas | |||
※Correct specifications depend on the actual model. All specifications are subject to change without prior notice.
All of our machines with 1 year guarantee.
Our machines are well favoured by customers due to easy operation, perfect performance, easy maintenance good & prompt after sale service.
If you need installment or training service,we can send engineer to your country,
help you install machines,training your workers to use machine(you need pay double way air tickets,salary,food,hotel for our engineer).
Install machines in Saudi Arabia.
If you buy one container machines,we will pack machine with stretch film and loading container directly (FCL full container load).
If you only buy one machine,we will pack machine with wooden pack,and loading container with Less Than Container Load（LCL）.
Our Main parts cooperator as following brand,but standard parts all made from China.
How To Find Polyethylene For Blown Film Extrusion?
Extrusion Film Extrusion use Polyethylene,such as
Low Density Polyethylene(LDPE),High Density Polyethylene(HDPE) and Linear Low Density Polyethylene(LLDPE),Polypropylene(PP).
Below are big brand material supplier in the world,they open office all over the world,you can check them in local market.
1.Sabic Saudi Basic Industries Corporation
2.ExxonMobil Chemical Company
3.Dow Chemical Company
