double layer stretch film machine

Double layer stretch film machine uses LLDPE as main material and adopts several kinds of resins to manufacture the single/double-side self-sticky stretch wrapping film. The film has good tensile strength,anti-pricking ability and impact strength. Its good shrinking memory function and self-sticky can make goods integrity to prevent goods from loosening and collapsing during transportation and being polluted by dust. The transparency and tensile strength of this product can make the packaging beautiful, economical and practical. The film can be widely used in wrapping of palletized goods. Its a good substitute for hot shrinking packaging film during transportation.

Technical Parameter:

Item/Model	KD-500*2	KD-1000*2
Screw diameter(mm)	55*2	65 *2
L/D ratio of screw (L/D)	28:1	28:1
width of die head (mm)	650	1250
Width of finished products(mm)	500(250*2rollers)	1000(500*2rollers)
Thickness of finished products (mm)	0.017-0.05	0.017-0.05
Structure of film layers	A/B	A/B
Max output (kg/h)	40	100
Linear speed of machinery (m/min)	10-120	50-100
Total power (KW)	50	140
Overall dimensions (LWH)m	61.52.5	1043
Weight (T)(About)	3	8

Optional Equipment:

1) Auto loader

2) Auto dry hopper

3) Motorize net changer

4) Hydraulic net changer

5) Air shaft

6) gule pump

CE Certificate
